Product Description
6.5dBi RFI CD8295 Wall/Pole Mount Omni Antenna. Supports GSM, 3G, 4G and 5G. Comes with 5m cable with SMA Male connector. For mounting bracket, patch leads, adapters and cable extensions, see ACCESSORIES below.
| Downloads | |||
 |
6.5dBi RFI CD8295 Omni Antenna Data Sheet | ||
The evolution continues with the release of the CD8200 5G cellular telemetry antennas. Like the CD2200 Series, the secret to it's outstanding performance lies in the use of the patented Meander™ radiating elements. These Meander™ circuits are coupled together to deliver extraordinary consistency in gain, coverage pattern and bandwidth. The result is a unique antenna able to operate across all mobile phone networks globally, housed in the one unit. With a 13mm stud, these antennas can be installed on electrical enclosures or other fixed objects.
Features:
- Wide Band Frequency 698-960 / 1710-2170 / 2300-2700 / 3400-3800MHz
- Patented PCB based collinear design offering the ultimate in pattern and gain stability
- Ideal for all new 4G LTE networks with true multi-band coverage
- High gain across all bands making it suitable for fringe and rural applications
Specifications are subject to change without notice. Picture may not be exact model as described.
ACCESSORIES
Other Details
| Mechanical Specification |
| Material | Black fibreglass radome with chrome ferrule/mounting stud |
| Colour | Black |
| Nett Weight Grams | 571 |
| Connector | FME Female with SMA Adapter |
| Cable | 5m LMR195 grade |
| Mounting Method | 13mm diameter mounting hole required |
| Dimensions mm | 805(h) x 15.6(diameter) |
Specifications are subject to change without notice.
