Product Description
15dBi Dual Wide Band Yagi/Grid Directional MiMo Antenna - Pole mount with SMA/M pigtails.
The Dual Yagi/Grid MiMO Antenna comprises a pair of antennas. These independent high performance antennas are provided with brackets and hardware allowing mounting on any pole or mast up to 45mm diameter. These antennas are made from aluminum and finished in black powder coat. Supports 3G, 4G and 5G NR MiMo networks. Ideal for wireless modem/routers.
 |
BC NG21DYAGI Data Sheet |
MiMo networks require the antennas be mounted at opposite 45º angles for correct polarisation (as shown in the pictures). Mounting brackets for 45º polarisation are included. Requires cables, fly leads and patch leads or adapters for connection to a wireless modem/router. See ACCESSORIES below for cables, patch leads, fly leads and mounting poles. MiMo Antennas explained!
Specifications are subject to change without notice. Picture may not be exact model as described.
ACCESSORIES
Other Details
| Mechanical Specification (per Antenna) |
| Material | Aluminium, Anodised and Powder Coat Finish |
| Colour | Black |
| Nett Weight Grams | 1650 |
| Connector | SMA Male |
| Cable | Cable 195 pigtail |
| Mounting Method | Pole-Mount Brackets, Suits pole diameter 25mm to 45mm |
| Dimensions mm | 1020(h) x 300(w) x 300(d) per antenna |
Specifications are subject to change without notice.
